STANDARD FEATURES

• Kawasaki 13hp Single Cylinder Engine
• Headlights, Tail & Brake Lights
• Steel DuraShield Epoxy Coated Chassis
• Body Finish Injection Moulded TPO
• Low Fuel/Oil Gauge
• Hour Meter
• 12-Volt Outlet
• Horn and Reverse Beeper
• K399 Load Star 205/65-10
• Comfort Grip Steering Wheel
• Solid Windshield with Frame
• Struts and Canopy
• 4 Insulated Sliding Drawers with Locks
• Slide out Trash/recycle storage bin system
• 2 plastic removable bin
• Lower Rear Corner Storage Sections - both sides of endcap
• Polar White Counter top
• Left & Right Side Mirrors
• Drawer Dividers (2)
• Consumable Ice Bin (1)
• Candy & Sandwich Tray (1)
• 6" Snack module with one dual-sided pullout polycarbon pegboard baskets (2) and chip strips (2)
• 18" Display Module with 4 adjustable shelves
• 3.0 liter airpots (2)
• 18" Cup & Display Module with 2 adjustable shelves/1 cup tray with 4 slots/1 beverage box and 1 dual airpot holder (18")
• Reversible insert for airpots and bottles
• Locking System for Holding & Changing Modules; 42" of Merchandising Module Space
• Shelves for napkins and bottles on back panel (3)
• Shelves on inside of doors (6)
• Coffee/Creamer serving caddy (2)
• 3.0 liter airpots (2)

OPTIONS/ACCESSORIES

• Food Warmer Module
• Color Options Available for Canopy, Unit & Vehicle
• All weather enclosures to Cab

SPECIFICATIONS

Dimensions

Overall Length: 373 cm
Overall Width: 137 cm
Overall Height (with canopy): 203 cm
Wheel Base: 237 cm
Front Wheel Track: 101 cm
Rear Wheel Track: 100 cm
Ground Clearance (at differential): 11 cm
Refresher Unit Material: 5000 Series Aluminium - Durable TGIC Polyester Powder Coating


Power

Powertrain: 4 Cycle, 24.5 ci (401cc)
Valvetrain: Single Cylinder OHV
Horsepower: 13.5 hp (10.1kW), Exceeds SAE J1940 Std
Electric System: Starter/Generator. Solid State Reg.
Battery (qty/type): One, 12 v Maintenance Free
Key or Pedal Start: Pedal Start
Air Cleaner: Industrial Rated Dry Cartridge
Lubrication: Pressurized Oil
Oil Filter: Spin On
Cooling System: Air Cooled
Fuel Capacity: 22.7 Litres
Speed Controller: 400 Amp Precision Drive System
Drive Train: Motor Shaft Direct Drive
Transaxle: Differential with Helical Gears
Gear Selection: Dash Mounted Forward-Neutral-Reverse
Rear Axle Ratio: 17.2:1 (Forward)   17.1:1 (Reverse)

Performance

Seating Capacity: 1 Person (2 Person Optional)
Dry Weight: 661 Kg
Curb Weight: 684 Kg
Vehicle Load Capacity: 460 Kg
Speed (level ground): 19 kph ± 0.8 kph (Forward)  17 kph ± 0.8 kph (Reverse)

Steering & Suspension

Steering: Self Compensating Rack and Pinion
Front Suspension: Leaf Springs with hydraulic Shock Absorbers
Rear Suspension:  Heavy Duty Leaf Springs with hydraulic Shock Absorbers
Service Brake: Four Wheel hydraulic Front Disk/Rear Drum
Parking Brake: Self-Compensating, Single Point Engagement
Tyres: Load Star 205/65-10

Body & Chassis

Frame: Welded steel with Durashield powder coat
Front Body & Finish: Injection Moulded TPO
Rear Body & Finish: Steel Base Coat/Clear Coat
Standard Colour: Forest Green
Optional Colour: Ivory
Available Seat Colours: Oyster
