STANDARD FEATURES

• 1 x Samsung Lithium Ion 2.2 Single Pack Maintenance Free Battery with Battery Management System
• AC Motor
• Automatic E Park Brake
• Induction Service Motor Brake with regenerative braking
• 48v Delta Q DC Lightweight Portable Charger,
• Modular Sun Canopy (Choice of Colours)
• Standard Contoured Seating (Choice of Colour)
• Premium Steering Wheel
• 2 x Sand Bottles
• Split Windshield
• State of Charge Meter
• Fender Scuff Guards
• Injection Moulded TPO Body finish with Choice of Colour
• E-Shield Enhanced Frame Coating
• Metallic Hubcaps ( Gold or Silver)
• Reverse Beeper
• Choice of Colour - Standard Colour: Forrest Green

OPTIONS/ACCESSORIES

• PACE Technology GPS
• Club and Ball Washer
• Drinks Cooler Esky
• Message holder
• Lockable Glovebox doors
• Rainbag Cover (Choice of Colour)
• Custom Premium Seats (Choice of colour)
• Dual USB Port

SPECIFICATIONS

• Overall Length: 240 cm
• Overall Width: 119 cm
• Overall Height (no canopy): 121 cm
• Overall Height (with canopy): 178 cm
• Wheel Base: 167 cm
• Front Wheel Track: 90 cm
• Rear Wheel Track: 97 cm
• Ground Clearance (at differential): 11 cm

• Power Source: 56 Volts DC
• Motor Type: 48 Volt AC
• Electric System: 56 Volt
• Battery (qty/type): 1 Samsung Lithium Ion 60 Amp Maintenance Free Battery Pack (Including Battery Management System)
• Key or Pedal Start: Pedal Start
• Battery Charger: Lithium World Charger 56VDC
• Speed Controller: 235 Amp AC Controller
• Drive Train: Motor Shaft Direct Drive
• Transaxle: Limited Slip Differential
• Gear Selection: Forward-Neutral-Reverse Integrated into Key Switch
• Rear Axle Ratio: 16.99:1

• Seating Capacity: 2 Person
• Dry Weight (without battery): 275 Kg
• Curb Weight: 298 Kg
• Vehicle Load Capacity: 360 Kg
• Outside Clearance Circle: 5.8 m
• Intersecting Aisle Clearance: N/A
• Speed (level ground): 13 - 24 kph ± 0.8 kph ( Programmable)
• Towing Capacity: 3 E-Z-GO Golf Cars with Approved permanent tow bar

• Steering: Double-ended Rack and Pinion
• Front Suspension: Independent A-arm Coil over Shock
• Rear Suspension:  Mono Leaf Springs with hydraulic Shocks
• Service Brake: Induction Motor
• Parking Brake: Automatic Electro Magnetic
• Tyres: Turf Tyres 18 x 8.5 - 8 (4 Ply Rated)

• Frame: Welded steel with powder coat protection
• Front Body & Finish: Injection Moulded, TPO
• Rear Body & Finish: Injection Moulded, TPO
• Standard Colour: Forest Green
• Standard Colours: Alamond, Black, Burgundy, Electric Blue, Flame Red, Inferno Red, Ivory, Metallic Charcoal, Orange, Patriot Blue, platinum, White
• Standard Seat Colour: Stone Biege
• Optional Seat Colours: Black or Oyster
• Pinstriping Colours: Pewter, White, Black, Gold.
